额定频率范围

f_nom

38.4MHz

Fundamental
  Please contact us about available frequencies.

储存温度

T_stg

-40°C   to +125°C

Store   as single product.

工作温度

T_use

-40°C   to +105°C

激励功率

DL

200µW   Max.

Recommended:   1 to 100µW

频率公差
  （标准）

f_tol

±10   × 10^-6

Please   contact us about reference temperature. Please contact us for inquiries.

频率与温度特性

（标准）

f_tem

±12   × 10^-6/-30°C to +85°C
  ±30 × 10^-6/-40°C to +105°C

Please   contact us for requirements not listed in this specifications.

负载电容

CL

6pF   to ∞

Please   specify.

串联电阻（ESR）

R1

50   W Max.

-40°C   to +105°C,

频率老化

f_age

±1   × 10^-6 / year Max.

+25°C,   First year

热敏电阻

―

Please   contact us about specifications.

热敏电阻B常数

―
